Plug-and-Play Desk Barcode Scanner Compact Desktop QR Reader for Office & Small Business
Features of desktop barcode scanners
The YJ-8658 high-performance desktop scanning device integrates a premium decoding core, capable of efficiently and
precisely recognizing all types of 1D and 2D barcodes. It offers dual-mode connectivity via 2.4G wireless and Bluetooth 4.0,
delivering stable long-range data communication. Optimized for warehouse operations, it can store up to 20,000 EAN13 product
barcodes, greatly reducing the burden of inventory tasks and enhancing work efficiency.
Advantages of desktop barcode scanners
1.Decoding Technology: Utilizes proprietary core decoding algorithms for rapid reading of barcodes across various quality
levels, combined with ultra-low power consumption and compatibility with multiple operating systems.
2.Product Characteristics: Enables seamless switching between wired, wireless, and Bluetooth dual modes to suit diverse
application scenarios. Equipped with a large-capacity secure storage module, it can retain over 20,000 barcodes in offline scanning
mode. A unique intelligent power management system ensures extended standby time. It supports mainstream barcode formats, featuring
convenient portability without extra burden.
3.Versatile Protocols: Compatible with 2.4G wireless transmission and Bluetooth HID, SPP, BLE protocols, facilitating flexible integration
with various terminal devices and offering excellent adaptability.
4.Decoding & Scanning Capabilities: Fully supports 1D/2D barcode recognition on both paper and screen substrates, efficiently handling
product packaging, electronic payment, and logistics label barcodes.
Application scenarios of desktop barcode scanners
Ideal for supermarket/convenience store cash registers, customer service desk barcode verification, warehousing and
logistics inventory management, O2O on-site redemption, and other scenarios, empowering mobile and efficient operations.
Technical Specifications of the Desktop Barcode Scanner
|
Model:
|
YJ-8658
|
|
Read code mode:
|
CMOS (global light burst)
|
|
Pixel:
|
640*480
|
|
Working current:
|
175mA is typical
|
|
Depth of view Angle:
|
30° V x 48° H (vertical horizontal)
|
|
Field of view Angle:
|
48° (H) x 30° (V)
|
|
Interface support:
|
USB, USB-COM, RS-232 (Optional)
|
|
Box size:
|
178*128*117mm (length * width * height)
|
|
Product weight:
|
Approximately 300g (not including packaging and accessories)
|
|
Rough weight:
|
Ap4 ately 500g (including packaging wire and accessories)
|
|
Cable standard:
|
Direct line: 1.8m
|
|
Pigment:
|
Black
|
|
Material quality:
|
ABS+PC
|
|
Sealing grade:
|
IP54
|
|
Fall height:
|
1.5m
|
|
Decoding ability:
|
1D: EAN13, EAN8, UPCA, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodaBar,
MSI, RSS
2D: QR, Data Matrix (DM), PDF417, support for mobile phone screen reading code
|
|
Material
|
ABS+TPU
|
|
Cable length
|
1 meter
|
|
Operating Temp.
|
-20 °C to 55°C
|
|
Storage Temp.
|
-20 ℃ to 60 ℃
|
|
Humidity
|
5%-95% (non-condensing)
|
|
Anti-seismic capacity
|
Passed 1.5m rolling drop test
|
FAQ
Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.
Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.
Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.
Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.
Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.
Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.
Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
