Compact Embedded 2D Barcode Scanner Plug-and-Play for POS, Kiosks & IoT Devices
Features of Embedded 1D/2D Barcode Scanners
YJ-ES215 stands as a highly integrated identification module with comprehensive functionalities. It merges powerful barcode
scanning and digital image capture capabilities, complemented by an ultra-slim design and extensive compatibility, enabling
flexible integration into diverse terminal devices.
Advantages of Embedded 1D/2D Barcode Scanners
1.Decoding Technology: Utilizes proprietary core decoding algorithms combined with a 300,000-pixel recognition resolution,
guaranteeing rapid reading speed and reliable precision.
2.Convenient Development: Offers full support for secondary development with a feature-rich SDK package that works
seamlessly with multiple OS, reducing the complexity of system integration.
3.Versatile Interfaces: Provides USB and TTL interfaces to cater to routine connection requirements.
4.Distinctive Design: Features an ultra-thin structure and is optimized for fast barcode reading in harsh outdoor environments
such as strong direct sunlight or backlighting.
5.Extensive Recognition Coverage: Powered by independently developed core decoding technology, it stably and efficiently
decodes barcodes of all quality grades—covering 1D/2D codes on paper or digital displays, from conventional barcodes to
mobile device-generated QR codes—with pinpoint accuracy.
6.Ultra-Slim Construction: Adopts an 8.3mm ultra-thin design with high integration, making it effortless to embed into a
variety of terminal devices.
Embedded 1D/2D Barcode Scanner Product Application Scenarios
Extensively integrated into various terminal devices across the IoT ecosystem, including self-service vending machines,
self-service information kiosks, smart logistics parcel lockers, queue management systems, self-service ticket dispensers,
and POS payment terminals.
Embedded 1D/2D Barcode Scanner Product Specifications
|
Capability
|
|
Collection method
|
Image type, CMOS Sensor
|
|
Picking rate
|
1 / 60 Seconds
|
|
Field of view Angle
|
Diagonal is 73°, 61° horizontal, and 48° vertical
|
|
Ability to read
|
|
Read the way
|
Close to the approach window, you can move the reading
|
|
Scan depth of field
|
test condition
|
depth of field
|
|
|
ITF 18bytes 7.5 mil commodity code
|
50~130mm
|
|
|
Code 39 4mil 10B
|
40~100mm
|
|
|
Code 128 14mil 17B (SF number)
|
85~300mm
|
|
|
QR Code 35mil (WeChat payment code)
|
25~440mm
|
|
Scan the Angle
|
The angle is 360°, elevation ± 60°, and bias ± 60°
|
|
Support code system
|
In line with the international and domestic general QR code standards:
QR Code, Data Matrix, PDF417, Hanxin, Dotcode, et al
|
|
|
In line with the international and domestic general one-dimensional code standards: UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128,ISBT 128, Code 39, Code93,
Code 11, Interleaved 2 of 5,Industrial 2 of 5,Matrix 25, Standard 25, Codabar,
MSI / MSI PLESSEY, GS1 DataBar et al
|
|
LED
|
|
Fill-in light
|
White
|
|
Physical parameters
|
|
Size (cm)
|
5.4*3.4*0.9 (length, width and height)
|
|
Weight
|
12g
|
FAQ
Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.
Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.
Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.
Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.
Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.
Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.
Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
