Access Control RFID NFC QR Code Card Reader RS232 Card Reader for Integrated Embedding
Product Definition of Fixed Barcode Scanners
YJ-ES902 is a 2D mini high speed desktop scanner with advanced CMOS image recognition technology.
It can easily read paper, goods, screen and other media 1D 2D barcodes.
Widely used in kiosk, turnstiles, vending machines, ticket checking machines.
Features of fixed barcode scanners
> Mini size, wide-angle design, suitable for all kinds of mobile phone code scanning.
> Good reading performance with soft light fill light.
> Support online upgrade, customized development and secondary development.
Advantages of fixed barcode scanners
1.Decoding Technology: Integrates proprietary core decoding algorithms, achieving fast and accurate reading of barcodes
across different quality grades and ensuring broader compatibility.
2.Technical Support: Provides full support for secondary development, accompanied by an SDK package compatible with
multiple systems, facilitating personalized integration.
3.Versatile Connectivity: Comes with dual USB and TTL interfaces, supporting various protocol standards to meet the diverse
connectivity needs of different devices.
4.Decoding & Scanning Capabilities: Offers full support for 1D/2D code recognition on paper or screen substrates, making it
suitable for multi-scenario applications.
5.High-Definition Accurate Recognition: Boasts 300,000 pixels and 5mil recognition precision, guaranteeing reliable identification
of small and low-clarity barcodes.
Technical Specifications of Fixed Barcode Scanners
|
Collection capacity
|
|
Method of collection
|
Imaging, CMOS sensor
|
|
picking rate
|
1 / 60 second
|
|
Field of view Angle
|
Horizontal 62°, vertical 48.5°
|
|
Reading ability
|
|
Recognition accuracy
|
≥5mil
|
|
Reading methods
|
Close, close reading
|
|
Scan the depth of field
|
test condition
|
depth of field
|
|
Code 128 10mil 18bytes paper code
|
35~200mm
|
|
Code 128 18bytes mobile code
|
35~230mm
|
|
QR code 10mil 160bytes paper code
|
30~120mm
|
|
DM 15mil 100bytes paper code
|
35~180mm
|
|
QR 18bytes mobile code
|
30~380mm
|
|
Code 128 10mil 18bytes paper code
|
35~200mm
|
|
The Angle of view
|
The corner Angle is 360°, the elevation Angle is ± 55°, and the deviation Angle is ± 55°
|
|
Supported coding system
|
Comply with international and domestic universal QR code standards:
QR Code, PDF417, DataMatrix (ECC200), etc
Complies with international and domestic universal one-dimensional code standards:
EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, limited RSS, extended RSS, etc
|
|
Print contrast
|
Minimum 25% reflection difference
|
|
LED
|
|
fill-in light
|
white
|
|
Physical parameters
|
|
size
(L x W x H)
|
54.5mm×34.7mm×17.5mm
|
|
weight
|
Less than 30g
|
|
joggle
|
|
jack
|
Micro USB cable socket
|
