Name: Barcode Scanner DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Module Reader for Android
Brand: Shenzhen Yuanjie Information Technology Co., Ltd.
SKU: YJ-ES103Q
Price: 30 USD
Availability: InStock

Barcode Scanner DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Module Reader for Android

Basic Information

Place of Origin:	Guangdong, China
Brand Name:	YJFIRST
Certification:	CE, ROHS, FCC, IEC, FDA
Model Number:	YJ-ES103Q

Minimum Order Quantity:	1Pcs
Price:	$30
Packaging Details:	Gift box
Delivery Time:	3-7 work days
Payment Terms:	T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
Supply Ability:	10000pcs/month

Contact Now

Product Name:

Barcode Scanner

Interface Type:

TL-232, USB (HID-KBW, Virtual Serial Port)

Optical Resolution:

5mil

Appearance Size:

20.98*14.82*11.11mm

Scan Element Type:

CMOS

Scan Speed:

30fps

Indication:

Buzzer & LED

Keywords:

Code Scanner Engine

Highlight:

USB barcode scanner module

high pixel QR code reader

Android compatible barcode scanner

DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Barcode Scanner Module Reader for Android

Why Choose Us?

---- Private mold, OEM/ ODM/ Customized all available for you.
----Own patents for the products.
----CE RoHS FCC EMC EMF BQB FDA CB certification.
----We promise 12 hours fast reply and 3 days shipment.
----1 year warranty.

Advantages of reading head of scanning code engine

YJ-ES103Q can read bar code and qr code.It use 640*480 CMOS,can read high density code,like long PDF417 passport code.

1. USB wired barcode scanner to capture 1D, 2D code on labels, paper, mobile phone or computer.

2. High-efficiency recognization and high upload speed for improving your working efficiency.

3. With buzzer for reminding you that the scanning successfully or not.

4. Compatible with USB and UART interface.

5. Over 180 configurable options

6. Macro support replace a string in the bar code with another

7. Programmable preamble postamble and termination strings

8.Superior reading performance utilizing advanced decoding algorithms

parameter

Scan performance
sensor	640×480 CMOS
lighting	white light LED
focusing	glow LED
Read code system	2D:QR Code, Data Matrix ,PDF417
Read code system	1D:Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5), Code39,Code93,Codabar
Read accuracy	≥5mil
contrast ratio	≥20%
Scan the Angle	The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
angle of field	Horizontal is 36°, and 27° vertical
Mechanical / electrical parameters
communication interface	TTL-232, USB (HID-KBW, virtual serial port)
Appearance size	20.9814.8211.11mm
Operating voltage (current / power consumption)	DC 5.0V/150mA/750mW
Standby current	70mA

Barcode Scanner DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Module Reader for Android 0

Barcode Scanner DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Module Reader for Android 1

Barcode Scanner DC5V High Quality Bar Code Qr Code USB UART Mega Pixel Module Reader for Android 2

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us

for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents

you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,

shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
