Name: Embedded OEM Barcode Scan Engine Access Control 2D Barcode Scanner Module Mini
Brand: Shenzhen Yuanjie Information Technology Co., Ltd.
SKU: YJ-ES103q
Price: 8.00 USD
Availability: InStock

Hotsale New Pos Qr Code Oem Auto Scan Access Control 2d Barcode Scanner Module

Product Description

YJ-ES103q is a practical embedded barcode scanner module with leading CMOS image recognition technology and

intelligent image recognition system. It can scan universal 1D 2D codes, support USB, TTL multiple interfaces, read

the paper, goods, screens, other media barcodes. Easily embedded in a variety of OEM products handheld, portable,

fixed and barcode collector, etc.

Features

1.Mini size, widely used in wireless machine, self-service terminal.
2.Read all mainstream 1D 2D barcodes in the market easily. (4mil)
3.Support USB barcode information transmission. ( languages customization)
4.High brightness, dark environment scanning, low power consumption.
5.Support multiple systems and languages, secondary development, customization.

6.Interface: USB, TTL.

7.Support multiple systems and languages, secondary development.

Technical Specifications of the Scanning Engine Read Head

YJ-ES103q Module Specification Sheet
Scan performance	sensor	640×480 CMOS
	lighting	white light LED
	focusing	glow LED
	Readable codes: 2D QR code, Data Matrix, PDF417 Readable codes: 2D QR code, Data Matrix,
	PDF417	Readable codes: 2D QR code, Data Matrix, PDF417
			Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,
		1D	ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar
	Reading accuracy is greater than or equal to 5mil	Reading accuracy is greater than or equal
	to 5mil
	Readable depth of field EAN-13 45mm-269mm (13mil 13 bytes) EAN-13 45mm-269mm (13mil 13 bytes) EAN-13 45mm-269mm (13mil 13 bytes)	Readable depth of field Readable depth of field
	Code39 35mm-119mm (5mil 7 bytes) 7 bytes)	Code39 35mm-119mm (5mil
	Code128 43mm-310mm (13mil10 bytes) (13mil10 bytes)	Code128 43mm-310mm
	QR code 19mm-185mm (15mil 30 bytes) (15mil 30 bytes)	QR code 19mm-185mm
	Data Marix 45mm-116mm (10 mils, 30 bytes) (10 mils, 30 bytes)	Data Marix 45mm-116mm
	PDF 417 40mm-105mm (6.67mil 30 bytes)	PDF 417 40mm-105mm (6.67mil 30 bytes)
	Contrast ratio is greater than or equal to 20%			Contrast ratio is greater than or equal to 20%
	The Angle of view		The corner Angle is 360°, the elevation Angle is ± 55°, and the deviation Angle is ± 55°
	angle of field		Horizontal 36°, vertical 27°
Mechanical/ele ctrical components count	communicati on interface		TTL-232, USB (HID-KBW, virtual serial port)
	Outer dimensions		21.5mm14.5mm10mm
	working voltage	/ Current / power consumption	DC 5.0V/150mA/750mW
	Wait for the electromotive force		70mA
enviromental parameter	working temperature		-20℃~+60℃
	storage temperature		-40℃~+80℃

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us

for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents

you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,

shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.

Tag:

Place of Origin:	Guangdong, China
Brand Name:	YJFIRST
Certification:	CE, ROHS, FCC, IEC, FDA
Model Number:	YJ-ES103q

Minimum Order Quantity:	1Pcs
Price:	1 - 100 pieces $16 100 -500 pieces $15.5 500 -1000 pieces $15
Packaging Details:	Gift box
Delivery Time:	3-7 work days
Payment Terms:	T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
Supply Ability:	20000pcs/month

Product Name:	OEM Barcode Scan Engine	Private Mold:	Yes
Products Status:	Stock	Interface Type:	Usb
Optical Resolution:	5mil	Scan Speed:	300 Times/sec
Highlight:	Embedded OEM Barcode Scan Engine , Access Control 2D Barcode Scanner Module , 2D Barcode Scanner Module Mini
