Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket

Name: Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket
Brand: Shenzhen Yuanjie Information Technology Co., Ltd.
SKU: YJ-ES908
Price: 17 USD
Availability: InStock

Brand Name:	YJFIRST
Model Number:	YJ-ES908
MOQ:	1pcs
Price:	$17
Delivery Time:	3-7 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE, ROHS, FCC, IEC, FDA

Product Name:

USB QR Code Scanner

Interface:

USB2.0/USB3.0

Application:

Commercial,industry

Scan Mode:

Handheld Rapid Scan

Decode Capabilities:

2D Code And Barcode

Scan Type:

Paper And Screen

Packaging Details:

Gift box

Supply Ability:

20000pcs/month

Highlight:

Portable USB QR Code Scanner

Desktop 2D Barcode Scanner

2D Barcode Scanner Commercial

Product Description

Portable Qr Code Wired Barcode Reader Usb Desktop Barcode Scanner 2d Barcode Scanner Bar Code Scanner

for Supermarket

Core Definition

An embedded barcode scanner (also called an integrated scanner or engine) is a compact module designed to be

permanently built into a larger device or system. Unlike handheld scanners, it lacks a physical trigger or housing meant

for user interaction. Its function is to automatically capture and decode barcode data for the host system.

Key Characteristics

Form Factor: Small, board-level or compact module (often PCB-mounted).

No Standalone Housing: Requires integration into a host device (kiosk, POS terminal, vending machine, medical

device, robot, etc.).

Fixed Mounting: Typically installed in a specific orientation within the host.

Automatic Scanning: Scans continuously, on sensor trigger (e.g., object presence), or via software command from the host.

Direct Integration: Connects electrically and physically to the host's mainboard/power.

Interface Focus: Uses low-level electronic interfaces (USB HID, USB CDC/VCP, UART/RS232, TTL, I2C, GPIO).

Products Description

Capability
Collection method	Image type, CMOS Sensor
Picking rate	1 / 60 Seconds
Field of view Angle	Horizontal 62°, and 48.5° vertical
Ability to read
Identification accuracy	≥5mil
Read the way	Close to, close to the reading
Scan depth of field	test condition	depth of field
	Code 128 10mil 18bytes Paper copy code	35~200mm
	Code 128 18bytes Mobile phone code	35~230mm
	QR 10mil 160bytes Paper copy code	30~120mm
	DM 15mil 100bytes Paper copy code	35~180mm
	QR 18bytes Mobile phone code	30~380mm
	Code 128 10mil 18bytes Paper copy code	35~200mm
Scan the Angle	The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
Support code system	In line with the international and domestic general QR code standards: QR Code, PDF417, DataMatrix (ECC200), etc In line with the international and domestic general one-dimensional code standards: EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11,MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
Print contrast	Minimum 25% of the reflection difference
LED
Fill-in light	White
Physical parameters
size (Long, width and height)	61mm ×51mm ×16.4mm
Weight	Less than 30g
Joggle
Joggle	4 PIN cable socket: USB KBW 4 PIN cable socket: Serial port TTL 232 or RS232 (5V or 3.3V)
Scan pattern	Command mode / induction mode / trigger mode
Read success tips	The LED and the buzzer
Data line (optional)	4PIN straight line
Enviromental parameter
Working temperature	-20℃ ~ 60℃
Storage temperature	-20℃ ~ 70℃
Humidity	Relative humidity: 5% ~ 95% (no condensation)
Ambient light	Max.100,000 Lux
Electrical parameters
Input voltage	5V or 3.3V
Working current	125mA
Standby current	85m A

Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket 0

Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket 1

Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket 2

Portable USB QR Code Scanner Desktop 2D Barcode Scanner Commercial For Supermarket 3

Company Profile

Shenzhen Yuanjie Information Technology Co., LTD. (YJFIRST) is one of the leading professional barcode scanner

manufacturers in China. YJFIRST specializes in barcode reading technology and has more than 10 years of experience in

the barcode scanning technology industry. YJFIRST's products include 1D and 2D barcode scanners, laser and CCD barcode

scanners, wireless barcode scanners, barcode scanner modules, scanning engines, omnidirectional scanning platforms, and

more. All products have passed CE, FCC, RoHS, IP54, RF certification, has been widely used in logistics, supermarket, retail,

medical, postal communication, office automation, manufacturing and other fields. We support OEM and ODM orders, welcome to visit our factory in China ! We will provide customers with high quality
products at competitive prices.

Exhibition

Applications

Transportation

FAQ

Q:Can you send sample? A:Yes, YJFIRST welcomes sample order to test. Please contact us for more details before placing sample order.

Q:Can we have our logo or company name to be printed on the product or package?
A:Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing,please contact us for more details.

Q:What's the shipping way?
A: There are DHL, Fedex, TNT, UPS. We also can ship the goods by your shipping account or other express agent you provided.

Q:What's the payment way?
A:We accept Alibaba online orders, PayPal ,T T, LC, Westem Union , MoneyGram.

Q:How about your product warranty?

A:Our oficiallyy promised warranty time is two years after delivery.

Q:How is your quality control?
A:Professional QC team and testing machine( Engine age testing, wire bending machine, switch life testing, shock resistance
testing). CE, FCC & ROHS certificated.

Q:If I come across any problem during product using, where I can get the support?
A:We support you technically 24h/7. Please send all your questions to us, and we will give the professional, patient,
expliantion by email or call in time.
