2D Barcode Scanner Box Commercial Square Box Code Scanner Customized

Basic Information
Place of Origin: China
Brand Name: YJFIRST
Certification: CE, ROHS, FCC, IEC, FDA
Model Number: YJ-5012
Minimum Order Quantity: 1
Price: 1 - 100 pieces $18 100 -500 pieces $17 500 -1000 pieces $16
Packaging Details: Gift box
Delivery Time: 3-7 work days
Payment Terms: T/T ,D/P,D/A ,L/C , MoneyGram ,Western Union
Supply Ability: 10000pcs/month
Product Name: Barcode Scanner Box Interface: USB
Application: Commercial,industry Decode Capabilities: 2D Code And Barcode
Scan Type: Paper And Screen Size (Long, Width And Height): 140mm*85mm*83mm
Highlight:

2D Barcode Scanner Box

,

Barcode Scanner Box Commercial

,

Square Box Code Scanner Customized

Mobile Phone Payment Terminal QR Code Scanner Reader 2D Barcode Scanner Desktop Scanning Flat


Features:

Scanning Function: Capable of quickly and accurately scanning various barcodes, such as 1D barcodes (like common commodity

barcodes) and 2D barcodes (such as QR codes), to decode the information contained within.

Compatibility: Usually works well with different systems, like POS (Point of Sale) systems in retail stores, inventory management

systems, etc., facilitating data integration.

Sensitivity: Equipped with a high - sensitivity sensor to recognize barcodes even in sub - optimal conditions, such as barcodes
with certain degrees of wear, low - contrast printing, or being displayed on digital screens.

Ease of Use: Designed with a user - friendly form factor, easy to place on countertops in business scenarios, and simple to

operate, often with plug - and - play capabilities for quick setup.


product application


Cashier Checkout: In supermarkets, convenience stores, and clothing stores, it quickly scans product barcodes at the

cash register, automatically identifies product information and prices, speeds up the checkout process, and reduces

customer waiting time. For example, in large - scale supermarkets, multiple such scanners are deployed at checkout

counters to handle a large number of customer transactions.

Inventory Management: Staff use it to scan barcodes on goods during stocktaking and replenishment. It can quickly

record the quantity and location of goods, helping managers accurately grasp inventory levels, optimize procurement

plans, and prevent overstocking or out - of - stock situations.

Products Description
Ability to read
Identification accuracy
≥5mil
Read the way
Close to, close to the reading
Scan depth of field
Test condition
Depth of field
QR 10mil 45bytes Paper copy code
0~120mm
QR 18bytes Mobile phone code
0~320mm
Code 128 10mil 9bytes Paper copy code
0~80mm
Code 128 18bytes Mobile phone code
0~150mm
Scan the Angle
The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
Support code system
In line with the international and domestic general QR code standards:
QR Code, PDF417, DataMatrix), etc
In line with the international and domestic general one-dimensional code standards:
EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
Print contrast
Minlowest 25% reflection difference
Interface
Standard USB
Scan pattern
Induction mode / command mode
Read success tips
LED, buzzer or speech
Data wire
1.5 m USB straight line
Enviromental parameter
Working temperature
-20℃ ~ 60℃
Storage temperature
-20℃ ~ 70℃
Humidity
Relative humidity: 5% ~ 95% (no condensation)
Ambient light
Max.100,000 Lux
Electrical parameters
Input voltage
5V (customizable 3.3V)
Working current
130mA (with no voice broadcast) / 380 mA (with voice broadcast)
Standby current
85m A

2D Barcode Scanner Box Commercial Square Box Code Scanner Customized 0


2D Barcode Scanner Box Commercial Square Box Code Scanner Customized 1

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
