5V / 3.3V Fixed Barcode Scanner Embedded Mounted Barcode Scanner

Name: 5V / 3.3V Fixed Barcode Scanner Embedded Mounted Barcode Scanner
Brand: Shenzhen Yuanjie Information Technology Co., Ltd.
SKU: YJ-ES906
Price: 17 USD
Availability: InStock

Brand Name:	YJFIRST
Model Number:	YJ-ES906
MOQ:	1Pcs
Price:	$17
Delivery Time:	3-7 work days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

CE, ROHS, FCC, IEC, FDA

Product Name:

Fixed Barcode Scanner

Light Source:

LED

Scan Mode:

Command Mode/Sense Mode/Auto Reading Mode

Dimensions (W X D X H):

5*2.4*1.6CM

Function:

Fast QR Code Scan

Keywords:

2d Barcode Qr Code Scanner

Packaging Details:

Gift box

Supply Ability:

20000pcs/month

Highlight:

5V Fixed Barcode Scanner

3.3V Fixed Barcode Scanner

Embedded Mounted Barcode Scanner

Product Description

Embedded Barcode Scanner Fixed Mount 1d Bar Code Scanner 1d 2d Barcode Scanner Module Barcode Reader

Parameter

Capability
Collection method	Image type, CMOS Sensor
Picking rate	1 / 60 Seconds
Field of view Angle	Horizontal 62°, and 48.5° vertical
Ability to read
Identification accuracy	≥5mil
Read the way	Close to, close to the reading
Scan depth of field	test condition	depth of field
	Code 128 10mil 18bytes Paper copy code	35~200mm
	Code 128 18bytes Mobile phone code	35~230mm
	QR 10mil 160bytes Paper copy code	30~120mm
	DM 15mil 100bytes Paper copy code	35~180mm
	QR 18bytes Mobile phone code	30~330mm
	Code 128 10mil 18bytes Paper copy code	35~200mm
Scan the Angle	The rotation angle was 360°, elevation angle ± 55°, and bias angle ± 55°
Support code system	In line with the international and domestic general QR code standards: QR Code, PDF417, DataMatrix (ECC200), etc In line with the international and domestic general one-dimensional code standards: EAN 13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, qualified RSS, extended RSS, etc
Print contrast	Minimum 25% of the reflection difference
LED
Fill-in light	White
Physical parameters
Size	52.41.6cm (Long, width and height)
Weight	About 9g
Joggle
Joggle	4 PIN cable socket: USB KBW 4 PIN cable socket: Serial port TTL 232 (5V or 3.3V)
Scan pattern	Command mode / induction mode / trigger mode
Read success tips	The LED and the buzzer
Data line (optional)	4PIN straight line
Enviromental parameter
Working temperature	-20℃ ~ 60℃
Storage temperature	-20℃ ~ 70℃
Humidity	Relative humidity: 5% ~ 95% (no condensation)
Ambient light	Max.100,000 Lux
Electrical parameters
Input voltage	5V or 3.3V
Working current	130mA
Standby current	87m A

Customization options

Customized logo (Min. order: 100 pieces)

Customized packaging (Min. order: 100 pieces)

Graphic customization (Min. order: 100 pieces)

FAQ
Q:Can you send sample? A:Yes, YJFIRST welcomes sample order to test. Please contact us for more details before placing sample order.

Q:Can we have our logo or company name to be printed on the product or package?
A:Yes, printer with logo or company name is acceptable, it will be accomplished by silk printing,please contact us for more details.

Q:What's the shipping way?
A: There are DHL, Fedex, TNT, UPS. We also can ship the goods by your shipping account or other express agent you provided.

Q:What's the payment way?
A:We accept Alibaba online orders, PayPal ,T T, LC, Westem Union , MoneyGram.

Q:How about your product warranty?

A:Our oficiallyy promised warranty time is two years after delivery.

Q:How is your quality control?
A:Professional QC team and testing machine( Engine age testing, wire bending machine, switch life testing, shock resistance testing). CE, FCC & ROHS certificated.

Q:If I come across any problem during product using, where I can get the support?
A:We support you technically 24h/7. Please send all your questions to us, and we will give the professional, patient, expliantion by email or call in time.
