Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired
Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired
Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired
Basic Information
Place of Origin: Guangdong, China
Brand Name: YJFIRST
Certification: CE, ROHS, FCC, IEC, FDA
Model Number: YJ-2008
Minimum Order Quantity: 1pcs
Price: YJ-J008(1D-Laser-wired) $10 YJ-J208(1D-Laser -Wireless) $16 YJ-J608(1D-Laser-BT-2.4G) $21 YJ-1008(1D-CCD-wired) $8 YJ-1208(1D-CCD-Wireless) $15 YJ-1608(1D-CCD-BT-2.4G) $19 YJ-2008(2D-CMOS-wired) $15 YJ-2208(2D-CMOS-Wireless) $18 YJ-2608(2D-CMOS-BT-2.4G) $
Packaging Details: Gift box
Delivery Time: 3-7 work days
Payment Terms: T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
Supply Ability: 20000pcs/month
Contact Now
Product Name: Handheld QR Code Scanner Private Mold: Yes
Products Status: Stock Interface Type: Usb
Optical Resolution: 5mil Scan Speed: 280 Times/sec
Highlight:

Customized Handheld QR Code Scanner

,

CMOS 2D 1D Barcode Scanner

,

2D 1D Barcode Scanner Wired

Handheld QR Code Scanner Wired UV 2D Barcode Scanner CMOS Barcode Scanner 1D 2D

Handheld Barcode Reader Scanning Gun

Products Description
Model:
YJ-2008 wired two-dimensional bar code scanner
Scan element type:
CMOS
Pixel:
640*480
Illuminant:
White light LED lighting, red light LED aiming
Scan pattern:
Key trigger, induction scan, automatic scan, continuous scan
Minimum resolution:
0.127mm(5mil) @Code 39, PCS=90%
Service environment:
0°C-50°C
Storage temperature:
-20℃~+70℃
Storage humidity:
5% -95% without condensation
Ambient illumination:
0~8,600 Lux (fluorescent) 0~100,000 Lux (daylight)
Input voltage:
5VDC±10%
Working current:
150mA
Depth of field:
EAN-13 45mm-269mm (13mil 13 bytes)
Code39 35mm-119mm (5mil 7 bytes)
QR Code 19mm-185mm (15mil 30 bytes)
Data Marix 45mm-116mm (10mil30 bytes)
PDF 417 40mm-105mm (6.67mil 30 bytes)
Field of view Angle:
36° (H) x 27° (V)
Interface support:
USB, USB-COM, RS-232 (optional)
Visual dimensions:
160mm * 60mm * 82mm (length * width * height)
Box size:
180mm * 110mm * 80mm (length * width * height)
Product weight:
Approximately 233g (not including packaging and accessories)
rough weight:
About 162.5g (including packing wire and accessories)
Cable standard:
Direct line: 1.8m
Pigment:
black
Material quality:
ABS+PC
Sealing grade:
IP52
Fall height:
1.5m
Decoding ability:
1D: Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar
2D: QR Code, Data Matrix ,PDF417
scanning speed:
280 Times / second

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired 0

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired 1

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired 2

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired 3

Customized Handheld QR Code Scanner CMOS 2D 1D Barcode Scanner Wired 4


FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
