Warehouse Gps Barcode Reader 2D Handheld Barcode Scanner Inventory Management System 1D Laser Code Scanning Gun

Product description

A handheld barcode scanner is a portable electronic device designed to capture and decode information from barcodes

or QR codes. It typically consists of an optical sensor (laser or image-based), a decoding system, and an ergonomic housing

for ease of use. The device connects to a computer or POS system via wired (USB, RS-232) or wireless (Bluetooth, Wi-Fi)

interfaces, enabling real-time data transfer. Handheld scanners are widely used in retail, warehousing, logistics, and inventory

management for efficient product identification, tracking, and transaction processing.

Features

Omni-directional/Laser/CCD scanning technology
Drop resistance & ergonomic design
Programmable function keys
Batch mode (for offline operation)
Auto-sleep/power-saving features

Parameter

Model:	YJ-1008 with wired red light
Scan element type:	CCD
Pixel:	1500 Pixels
Illuminant:	A red-light diode was visible at 620nm
Scan pattern:	Key trigger, induction scan, automatic scan, continuous scan
Minimum resolution:	0.127mm(5mil) @Code 39, PCS=90%
Service environment:	0°C-50°C
Storage temperature:	-20℃~+70℃
Storage humidity:	And 5% -95% without condensation
Ambient illumination:	0~8,600 Lux (fluorescent) 0~100,000 Lux (daylight)
Input voltage:	5VDC±10%
Working current:	29mA～157mA
Depth of view Angle:	30° V x 48° H (vertical horizontal)
Field of view Angle:	48° (H) x 30° (V)
Interface support:	USB, USB-COM, RS-232 (Optional)
Visual dimensions:	160mm60mm82mm (length * width * height)
Box size:	180mm×110mm×80mm (length * width * height)
Product weight:	Approximately 168.5g (not including packaging and accessories)
Rough weight:	223.5g (including packing wire and accessories)
Cable standard:	Direct line: 1.8m
Pigment:	black
Material quality:	ABS+PC
Sealing grade:	IP52
Fall height:	1.5m
Decoding ability:	1D: EAN 13, EAN 8, UPCA, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, A, Code11,CodaBar, MSI, RSS, anti-phase barcode, Brazilian bank code, et al
Scanning speed	280 Times / second

2D 1D Warehouse Barcode Scanners Black GPS Barcode Scanner 2

FAQ

Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.

Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us

for more details.

Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents

you provide.

Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.

Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.

Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,

shock resistance testing). CE, FCC & ROHS certified.

Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.

Tag:

Place of Origin:	Guangdong, China
Brand Name:	YJFIRST
Certification:	CE, ROHS, FCC, IEC, FDA
Model Number:	YJ-1008

Minimum Order Quantity:	1Pcs
Price:	YJ-J008(1D-Laser-wired) $10 YJ-J208(1D-Laser -Wireless) $16 YJ-J608(1D-Laser-BT-2.4G) $21 YJ-1008(1D-CCD-wired) $8 YJ-1208(1D-CCD-Wireless) $15 YJ-1608(1D-CCD-BT-2.4G) $19 YJ-2008(2D-CMOS-wired) $15 YJ-2208(2D-CMOS-Wireless) $18 YJ-2608(2D-CMOS-BT-2.4G) $
Packaging Details:	Gift box
Delivery Time:	3-7 work days
Payment Terms:	T/T ，D/P，D/A ，L/C ， MoneyGram ，Western Union
Supply Ability:	20000pcs/month

Product Name:	Warehouse Barcode Scanners	Single Gross Weight:	0.300 Kg
Brand Name:	YJFIRST	Warranty(year):	1-Year
Private Mold:	Yes	Color:	Black
Highlight:	2D Warehouse Barcode Scanners , 1D Warehouse Barcode Scanners , Black GPS Barcode Scanner
