Compact Bluetooth Handheld Barcode Scanner 1D 2D QR Code Reader Support Mobile Phone Connection
Features of the Portable Bluetooth Barcode Scanner
The YJ-6601 is a high-performance portable scanning device equipped with an excellent decoding core, capable
of efficiently and accurately recognizing a wide range of 1D and 2D barcodes. It integrates 2.4G wireless transmission
and Bluetooth 4.0 dual-mode communication, ensuring stable long-distance data transfer. Specifically designed for
warehouse use, it can store up to 50,000 EAN13 product barcodes, greatly reducing the effort required for inventory tasks.
Characterized by a compact size and modern design, it comes with a back buckle for easy carrying, allowing unrestricted
usage.
Advantages of Portable Bluetooth Barcode Scanners
1.Decoding Technology: Adopts proprietary core decoding algorithms for fast reading of barcodes of varying qualities,
combined with ultra-low power consumption and compatibility with multiple operating systems.
2.Product Traits: Supports seamless switching between wired, wireless, and Bluetooth dual modes to meet the needs of
diverse scenarios. Equipped with a large-capacity secure storage module, it can store over 50,000 barcodes in offline scanning
mode. A unique intelligent power management system ensures ultra-long standby time. It supports mainstream barcode types,
with a compact and portable design.
3.Rich Protocol Compatibility: Supports 2.4G wireless transmission and is compatible with Bluetooth HID, SPP, BLE protocols,
facilitating flexible connection to various terminal devices and offering strong adaptability.
Application Scenarios for Portable Bluetooth Barcode Scanners
Suitable for supermarket/convenience store checkout, customer service desk barcode verification, warehousing and logistics
inventory inbound/outbound, manufacturing process tracing, O2O on-site redemption, and other scenarios, providing strong support
for mobile and efficient workflows.
Technical Specifications of Portable Bluetooth Barcode Scanner
|
YJ-6601 2D mini portable barcode scanner with clip
|
|
Wireless
|
15 - 20m
|
|
Connection
|
USB+2.4G wireless with dongle +bluetooth
|
|
Barcode
|
1D and 2D barcodes
|
|
Clip
|
yes
|
|
Color
|
Black and white
|
|
Optical Source
|
620nm Visible red light diode
|
|
Imaging Sensor
|
CMOS(Image)
|
|
Resolution Ratio
|
752×480
|
|
Image Resolution
|
≥ 4mil
|
|
Minimum Contrast
|
≥ 30%
|
|
Decoding Speed
|
300times/s
|
|
Barcode Sensitivity
|
Tilt
|
±55°
|
|
Rotate
|
±25°
|
|
Deflection
|
±55°
|
|
Data Interface Port
|
RJ45
|
|
Size(Length x Width x Height)
|
107*39.6*42 mm
|
|
Weight
|
97g
|
|
Indicator
|
Siren and LED light
|
|
Battery Capacity
|
Building lithium battery 1800mA
|
|
Max.Power
|
1092mw
|
|
Working Voltage
|
DC5V
|
FAQ
Q: Can you send a sample?
A: Yes, YJFIRST welcomes sample orders to test. Please contact us for more details before placing a sample order.
Q: Can we have our logo or company name printed on the product or package?
A: Yes, printing with the logo or company name is acceptable; it will be accomplished by silk printing. Please contact us
for more details.
Q: What's the shipping method?
A: There are DHL, FedEx, TNT, and UPS. We can also ship the goods using your shipping account or other express agents
you provide.
Q: What's the payment method?
A: We accept Alibaba online orders, PayPal, T/T, LC, Western Union, and MoneyGram.
Q: How about your product warranty?
A: Our formal guarantee period is one year after delivery.
Q: How is your quality control?
A: We have a professional QC team and testing machines (engine age testing, wire bending machine, switch life testing,
shock resistance testing). CE, FCC & ROHS certified.
Q: If I come across any problems during product use, where can I get support?
A: We provide technical support 24/7. Please send all your questions to us and we will give you professional and patient
explanations via email or call in time.
